Here is an example JSON payload for creating an advertising campaign request. This request is sent via a POST method to the endpoint: https://api.dooh.one/api/v2/agency/<dsp_agency_id>/dsp/request/.

{
  "name": "Test Campaign 1",
  "description": "Optional description of the campaign",
  "platform": 6,
  "industry": {
    "version": 2,
    "id": "248"
  },
  "start_date": "2021-03-01",
  "end_date": "2021-03-09",
  "time_range": [43200, 86399],
  "schedule": {
    "mon": true,
    "tue": false,
    "wed": true,
    "thu": false,
    "fri": true,
    "sat": false,
    "sun": true
  },
  "ad_duration": 10,
  "ad_rate_per_hour": 12,
  "payment_model": "cpv",
  "payment_model_limit": 1000,
  "areas": [
    {
      "title": "Moscow, Russia",
      "action": "include",
      "latitude": 55.75583,
      "longitude": 37.61778,
      "radius": 100
    }
  ],
  "age": [18, 65],
  "gender": "female",
  "resolutions": ["1920x1080"],
  "budget": 1000000,
  "max_bid": 7.5
}

Key Parameter Details:

• name: The name of the campaign, maximum 128 characters.

• platform: The unique ID of the advertising network.

• industry: Categorizes the campaign using IAB Content Category Taxonomy (Version 1.0 or 2.0).

• start_date / end_date: The active dates for the campaign in YYYY-MM-DD format.

• time_range: The daily window for ad display, defined in seconds from the start of the day (e.g., [43200, 50400] for 12:00 PM to 2:00 PM).

• schedule: A JSON object specifying which days of the week the ads should be shown.

• payment_model: Supports ad_plays (impressions), cpm (reach), or cpv (guaranteed views).

• areas: A list of geographic zones to either include or exclude based on latitude, longitude, and a radius in kilometers.

• max_bid: The maximum price the DSP is willing to pay. For ad_plays, this is the cost per 1,000 displays; for cpv, it is the cost per single guaranteed view.
